Axial Color Code Capacitor is a passive component with cylindrical shape and axial lead. Its appearance is almost identical to the color ring resistance, and parameters such as capacity, error, and withstand voltage are identified by the color ring.
Features:
1. Appearance and Installation
Axial lead, suitable for through hole welding (THT), stable installation, and vibration resistance.
The cylinder has a small volume and can be installed horizontally/vertically, flexibly adapting to space.
2. Electrical Characteristics
Non polarized, capable of bidirectional operation.
Ceramic type: Good high-frequency characteristics and high stability (such as C0G).
Thin film type: high insulation resistance, low ESR, low loss, suitable for audio/coupling.
Capacity range: 1pF~10 μ F; Voltage resistance: 50V~3kV.
3. Environment and reliability
Epoxy encapsulation, moisture-proof, heat-resistant, and high mechanical strength.
Wide working temperature range (-55 ℃~+125 ℃), long lifespan.
Applications：
1. Classic/Retro Equipment: Vintage radios, televisions, speakers, instruments (alternative maintenance).
2. Audio circuit: frequency divider, coupling/bypass, tone control (thin film type for excellent sound quality).
3. Industrial/power supply: filtering, decoupling, absorption circuits (high voltage/high reliability scenarios).
4. Automotive electronics: ECU, sensors, ignition system (shock resistant, wide temperature range).
5. Military/aviation: high reliability, radiation resistance, extreme environment.
